Supplied & installed by iConusCESS-105K215AL
C&I storage · 105 kW / 215 kWh · All-in-one outdoor cabinet
Price on request
Quantity
CESS-105K215AL · Price on request
C&I storage · Hanchu ESS
215kWh
An all-in-one outdoor cabinet with battery, modular PCS, EMS, distribution and fire fighting built in. Add the combiner cabinet for seamless on/off-grid switching.
105 kW · Rated AC power768 V · Rated voltage<20 ms · On/off-grid switchIP54 · Outdoor cabinet
105 kWRated AC power
768 VRated voltage
<20 msOn/off-grid switch
IP54Outdoor cabinet
Features
Why this c&i storage.
Home batteries · Hybrid inverters · C&I storage · EV chargers, supplied and supported by iConus.
Hanchu ESSCESS-105K215ALOutdoor cabinet
All-in-oneBattery, modular PCS, EMS and fire fighting in one cabinet.
Front maintenanceLess service space and floor area needed.
Layered fire safetySmoke and heat detection, water-based and perfluorohexanone suppression.
Peak shavingEnergy arbitrage between off-peak and peak prices.
Microgrid integrationBalances solar, charging, diesel and grid.
WeatherproofIP54, rated for wind, sand and rain.
Where it fits
Built for business.
Our engineers model your load profile and tariff before recommending a size.
Request a site studyPeak shavingCharge when power is cheap, discharge at peak times to cut demand charges.
Backup for critical loadsKeep cold rooms, servers and production lines running through outages.
Solar + generator hybridStore solar and cut diesel run-hours on sites with weak or no grid.
Grows with youAdd cabinets or modules as demand increases.
Specifications
The details.
- Rated capacity
- 215 kWh
- Rated AC power
- 105 kW
- Rated voltage
- 768 V DC
- Battery type
- LFP (LiFePO4)
- Max charge / discharge
- 140 A
- Grid
- 400 V 3P4W · 50 Hz
- Power factor
- 0.99
- Cooling
- Smart air cooling (3.2 kW)
- Protection
- IP54
- Operating temperature
- −30 to +50 °C
- EMS interface
- Modbus TCP
- Dimensions (W×D×H)
- 1,500 × 1,490 × 2,348 mm
- Weight
- 2,500 kg
- Combiner cabinet
- Optional · on/off-grid switching < 20 ms
