Order-in
Supplied & installed by iConusHC-EV-AC-07K / 11K / 22K
EV charger · 7–22 kW · AC wallbox
Price on request
Choose a model · HC-EV-AC-07K
Quantity
HC-EV-AC-07K / 11K / 22K · Price on request
EV charger · Hanchu ESS
7–22kW
An AC wallbox for homes, offices and fleets. Pair it with solar and storage and your car charges on sunshine.
OCPP 1.6J · Works with charging platformsType A + 6 mA · DC leakage detectionIP65 · Socket or cable version4.3" · LCD screen (optional)
OCPP 1.6JWorks with charging platforms
Type A + 6 mADC leakage detection
IP65Socket or cable version
4.3"LCD screen (optional)
Features
Why this ev charger.
Home batteries · Hybrid inverters · C&I storage · EV chargers, supplied and supported by iConus.
Hanchu ESSHC-EV-AC-07K / 11K / 22KCharging under a solar canopy
App, RFID or plug & playSeveral ways to start a charge.
Dynamic load balancingShares power with the house so the main fuse never trips.
PEN fault protectionPlus over/under-voltage, surge and earth-leakage protection.
Solar + storage awareIntegrated control with Hanchu energy systems.
Wall or post mountCable or socket versions.
Metering optionBuilt-in MID meter for billing.
Charging time
How fast will
your car charge?
Car battery size
Charger
10% → 90%
–
–
Energy added
– kWh
– kWh
11 and 22 kW need a three-phase supply, and your car’s on-board charger must accept that power.
Specifications
The details.
- Rated power
- 7 / 11 / 22 kW
- Input voltage
- 230 V (7 kW) · 400 V three-phase (11 / 22 kW)
- Output current
- 32 / 16 / 32 A
- Connector
- Type 2 socket or 5 m cable
- Authentication
- App · RFID · QR code (optional)
- Communication
- Wi-Fi · Bluetooth · LAN / 4G (optional) · RS485
- Protocol
- OCPP 1.6J
- Leakage protection
- Type A + DC 6 mA
- Dimensions (W×H×D)
- 240 × 460 × 145 mm
- Weight
- 6.5–8.5 kg
- Protection
- IP54 / IP65
- Operating temperature
- −30 to +50 °C
- Certificates
- CE · CB
- Warranty
- 3 years
Downloads
DatasheetPDF · from Hanchu ESSInstallation guidePDFQuestions about fitting it?Our engineers check compatibility before you buy.Chat on WhatsApp
