In stock
Supplied & installed by iConusHOME-ESS-LV-5.12K
Low-voltage stackable home battery · 5.12–81.92 kWh
Price on requestper module
Battery modules
Total storage: 10.24 kWh
HOME-ESS-LV-5.12K · Price on request
Low-voltage battery · Hanchu ESS
5.12–81.92kWh
Start with one 5.12 kWh module and grow to sixteen. Safe LFP chemistry, smart protection and plug-and-play installation.
51.2 V · Nominal voltageLFP · LiFePO4 cells95% · Depth of dischargeIP54 · Dust & splash protected
51.2 VNominal voltage
LFPLiFePO4 cells
95%Depth of discharge
IP54Dust & splash protected
Features
Built safe. Built smart.
Eight layers of engineering that keep your power on and your home safe.
Smart BMSIntelligent managementThe built-in BMS monitors voltage, current and temperature to optimise every charge and discharge.
Submerged fire protectionAn integrated hot-aerosol system suppresses flames inside the module.
LiFePO4 cellsResistant to thermal runaway, with long cycle life and high efficiency.
Convenient installationWall-mount bracket, plug-and-play terminals and automatic module recognition.
Real-time monitoringVoltage, current and temperature detection around the clock.
Multiple protectionsGuards against overvoltage, overcurrent, overheating and cell imbalance.
External circuit breakerWatches current and cuts the circuit automatically when needed.
Ultra safetyLayered battery-management protections keep the system safe, day and night.
Explore the battery
Tap a point to see
what's inside.
01 / 04Smart BMS
Tracks voltage, current and temperature in real time and balances every cell for a longer life.
Point positions are illustrative. Confirm against the Hanchu datasheet.
Hanchu iESS cloud & app
Your energy,
in your pocket.
See what your panels produce, what your home uses and what's stored, live. iConus sets up the app for you at commissioning.
Remote schedulingCharge when power is cheap, discharge at peak times
Over-the-air upgradesNew features arrive without a site visit
History & analyticsDaily, monthly and yearly energy reports
My home systemLive
78%Battery charged
18.4 kWhToday's solar
92%Grid avoided
Illustrative screen with sample values
Build your stack
How much backup
do you need?
What do you want to keep running?
Total storage
10.24 kWh
10.24 kWh
Usable at 95% depth
9.7 kWh
9.7 kWh
Estimated backup
≈ 6.5 hours
≈ 6.5 hours
At a steady 1.5 kW load. Real results vary.
Specifications
The details.
- Model
- HOME-ESS-LV-5.12K
- Nominal energy
- 5.12 kWh
- System capacity
- 5.12–81.92 kWh (1–16)
- Nominal voltage
- 51.2 V
- Cell type
- LiFePO4 (LFP)
- Charge / discharge current
- 100 A
- Max parallel current
- 220 A
- Depth of discharge
- 95%
- Communication
- CAN · RS485 · Wi-Fi · Bluetooth
- Ingress protection
- IP54
- Weight
- 46.5 kg
- Certifications
- IEC 62619 · CE-EMC · UN38.3
- Dimensions (W×D×H)
- 338 × 138.5 × 600 mm
- Warranty
- 10 years
Downloads
{ic(*DOC)}{n}PDF{ic("M12 4v12M7 11l5 5 5-5M5 20h14")}{ic(*DOC)}{n}PDF{ic("M12 4v12M7 11l5 5 5-5M5 20h14")}{ic(*DOC)}{n}PDF{ic("M12 4v12M7 11l5 5 5-5M5 20h14")}Questions about fitting it?Our engineers can check your inverter and wiring before you buy.Chat on WhatsApp
Complete the system
Pairs well with
Mix partners in one quote. iConus coordinates delivery and installation.
Photo coming soon
